ASME/ANSI B18.5-8-2008

114° Countersunk Square Neck Bolts-Table8

Supplier
Inquiry
Dimension drawing
3D drawing
Collapse
Click to use the roll zoom function
0%

ASME/ANSI B18.5-8-2008

114° Countersunk Square Neck Bolts-Table8

Nom
P
ds max
ds min
dk max
dk min
k max
k min
s max
s min
k1 max
k1 min
#10
24|32
0.199
0.182
0.548
0.5
0.131
0.112
0.199
0.185
0.125
0.094
1/4
20|28|32|26
0.26
0.237
0.682
0.625
0.154
0.135
0.26
0.245
0.156
0.125
5/16
18|24|32|22
0.324
0.298
0.821
0.75
0.184
0.159
0.324
0.307
0.219
0.188
3/8
16|24|32
0.388
0.36
0.96
0.875
0.212
0.183
0.388
0.368
0.25
0.219
7/16
14|20|28
0.452
0.421
1.093
1
0.235
0.205
0.452
0.431
0.281
0.25
1/2
13|20|28|16
0.515
0.483
1.233
1.125
0.265
0.229
0.515
0.492
0.312
0.281
5/8
11|18|24|14
0.642
0.605
1.495
1.375
0.316
0.272
0.642
0.616
0.406
0.375
3/4
10|16|20|12
0.768
0.729
1.754
1.625
0.368
0.314
0.768
0.741
0.5
0.469
