QC/T 330-1999
Reed nut for automobile
Nom
P
d1
h1 max
h1 min
s min
H max
h max
h min
ST3.9
1.3
6.8
0.4
0.36
16
2.8
1.3
0.6
ST4.8
1.6
7.8
0.6
0.55
20
2.8
1.3
0.6
ST6.3
1.8
8.8
0.8
0.73
25
2.8
1.3
0.6
